Through Bore Slip Rings

The inner diameter of through bore slip rings allows an easy mounting on a shaft. These slip rings are the ideal solution for rotary transmission requirements on machine tools, revolving doors, rotary tables, robotic arms and much more. The maintenance-free slip rings combine a compact design with impressive performance and are available immediately!
The MAVERICK series offers various models that differ in their dimensions, the number of transmission paths and the transmittable current and voltage values.
All models can be rotated at up to 300 rpm and meet the requirements of protection class IP50. Thanks to the cable length of 250 mm each on the rotor and stator, the slip rings can be easily connected to existing systems.
Filter
Maverick 12-way 10 A / 250 V slip ring
Product number: 7KC000004
Maverick 12-way 10 A / 250 V slip ring
Details
Inner Diameter: 50 mm
Outer Diameter: 121 mm
Total Length: 88.7 mm
Number of Tracks: 12
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€698.00

plus VAT & plus handling costs

Maverick 6-way 10 A / 400 V slip ring
Product number: 7KC000003
Maverick 6-way 10 A / 400 V slip ring
Details
Inner Diameter: 38.1 mm
Outer Diameter: 101 mm
Total Length: 58.4 mm
Number of Tracks: 6
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€410.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 10A / 250V
Product number: 7KC000041
Maverick Slip Ring 12-Track 10A / 250V
Details
Inner Diameter: 12.7 mm
Outer Diameter: 58 mm
Total Length: 82.1 mm
Number of Tracks: 12
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€278.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 10A / 400V
Product number: 7KC000032
Maverick Slip Ring 12-Track 10A / 400V
Details
Inner Diameter: 38.1 mm
Outer Diameter: 101 mm
Total Length: 82.4 mm
Number of Tracks: 12
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€348.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 10A / 400V
Product number: 7KC000002
Maverick Slip Ring 12-Track 10A / 400V
Details
Inner Diameter: 25.4 mm
Outer Diameter: 88 mm
Total Length: 81.5 mm
Number of Tracks: 12
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€460.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 15A / 250V
Product number: 7KC000026
Maverick Slip Ring 12-Track 15A / 250V
Details
Inner Diameter: 50 mm
Outer Diameter: 121 mm
Total Length: 98.3 mm
Number of Tracks: 12
Current per Track: 15 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€450.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 15A / 400V
Product number: 7KC000010
Maverick Slip Ring 12-Track 15A / 400V
Details
Inner Diameter: 25.4 mm
Outer Diameter: 88 mm
Total Length: 91.1 mm
Number of Tracks: 12
Current per Track: 15 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€368.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 15A / 400V
Product number: 7KC000018
Maverick Slip Ring 12-Track 15A / 400V
Details
Inner Diameter: 38.1 mm
Outer Diameter: 101 mm
Total Length: 92 mm
Number of Tracks: 12
Current per Track: 15 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€395.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 5A / 250
Product number: 7KC000006
Maverick Slip Ring 12-Track 5A / 250
Details
Inner Diameter: 25.4 mm
Outer Diameter: 88 mm
Total Length: 73.1 mm
Number of Tracks: 12
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€342.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 5A / 250V
Product number: 7KC000022
Maverick Slip Ring 12-Track 5A / 250V
Details
Inner Diameter: 50 mm
Outer Diameter: 121 mm
Total Length: 80.3 mm
Number of Tracks: 12
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€415.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 5A / 250V
Product number: 7KC000038
Maverick Slip Ring 12-Track 5A / 250V
Details
Inner Diameter: 12.7 mm
Outer Diameter: 58 mm
Total Length: 64.1 mm
Number of Tracks: 12
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€278.00

plus VAT & plus handling costs

Maverick Slip Ring 12-Track 5A / 250V
Product number: 7KC000014
Maverick Slip Ring 12-Track 5A / 250V
Details
Inner Diameter: 38.1 mm
Outer Diameter: 101 mm
Total Length: 74 mm
Number of Tracks: 12
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€359.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 10A / 250V
Product number: 7KC000042
Maverick Slip Ring 18-Track 10A / 250V
Details
Inner Diameter: 12.7 mm
Outer Diameter: 58 mm
Total Length: 109.7 mm
Number of Tracks: 18
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€371.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 10A / 250V
Product number: 7KC000031
Maverick Slip Ring 18-Track 10A / 250V
Details
Inner Diameter: 50 mm
Outer Diameter: 121 mm
Total Length: 112.7 mm
Number of Tracks: 18
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€526.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 10A / 400V
Product number: 7KC000033
Maverick Slip Ring 18-Track 10A / 400V
Details
Inner Diameter: 38.1 mm
Outer Diameter: 101 mm
Total Length: 106.4 mm
Number of Tracks: 18
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€456.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 10A / 400V
Product number: 7KC000035
Maverick Slip Ring 18-Track 10A / 400V
Details
Inner Diameter: 25.4 mm
Outer Diameter: 88 mm
Total Length: 104.9 mm
Number of Tracks: 18
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€441.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 15A / 250V
Product number: 7KC000027
Maverick Slip Ring 18-Track 15A / 250V
Details
Inner Diameter: 50 mm
Outer Diameter: 121 mm
Total Length: 127.1 mm
Number of Tracks: 18
Current per Track: 15 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€564.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 15A / 400V
Product number: 7KC000011
Maverick Slip Ring 18-Track 15A / 400V
Details
Inner Diameter: 25.4 mm
Outer Diameter: 88 mm
Total Length: 119.3 mm
Number of Tracks: 18
Current per Track: 15 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€463.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 15A / 400V
Product number: 7KC000019
Maverick Slip Ring 18-Track 15A / 400V
Details
Inner Diameter: 38.1 mm
Outer Diameter: 101 mm
Total Length: 120.8 mm
Number of Tracks: 18
Current per Track: 15 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€505.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 5A / 250V
Product number: 7KC000023
Maverick Slip Ring 18-Track 5A / 250V
Details
Inner Diameter: 50 mm
Outer Diameter: 121 mm
Total Length: 100.1 mm
Number of Tracks: 18
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€492.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 5A / 250V
Product number: 7KC000039
Maverick Slip Ring 18-Track 5A / 250V
Details
Inner Diameter: 12.7 mm
Outer Diameter: 58 mm
Total Length: 82.7 mm
Number of Tracks: 18
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€341.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 5A / 250V
Product number: 7KC000007
Maverick Slip Ring 18-Track 5A / 250V
Details
Inner Diameter: 25.4 mm
Outer Diameter: 88 mm
Total Length: 92.3 mm
Number of Tracks: 18
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€418.00

plus VAT & plus handling costs

Maverick Slip Ring 18-Track 5A / 250V
Product number: 7KC000015
Maverick Slip Ring 18-Track 5A / 250V
Details
Inner Diameter: 38.1 mm
Outer Diameter: 101 mm
Total Length: 93.8 mm
Number of Tracks: 18
Current per Track: 5 A
Rating Voltage: 250 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€435.00

plus VAT & plus handling costs

Maverick Slip Ring 24-Track 10A / 250V
Product number: 7KC000029
Maverick Slip Ring 24-Track 10A / 250V
Details
Inner Diameter: 50 mm
Outer Diameter: 121 mm
Total Length: 136.7 mm
Number of Tracks: 24
Current per Track: 10 A
Rating Voltage: 250 V / 400 V
Max. Rotating Speed: 300 rpm
Lead Wire Length: 250 mm
Protection Class: IP50

Ready for shipment in 2-5 days

€615.00

plus VAT & plus handling costs

In the example picture, a MAVERICK is mounted on a rotating shaft.
Four grub screws connect the rotor to the shaft, which is passed through the inner diameter.
There are several mounting options on the stator in order to integrate the supplied bracket into a customer-supplied holdfast to prevent it from rotating.
Max. Speed: 300 rpm
Cable length stator: 250mm
Cable length rotor: 250mm
Protection class: IP50

The MAVERICK series impresses thanks to its versatility. It transmits power, data and signals and is used in the following areas, among others:
  • Rotary tables
  • robot arms
  • revolving doors
  • Machine tools and much more.

Installation of a MAVERICK slip ring

Turning center (rotor):
It is mounted on the shaft by tightening the four grub screws.
The rotating inner part of the MAVERICK is then driven by the shaft.

Outer housing (stator):
The outer housing of the MAVERICK is secured against rotation by the bracket supplied. A customer-supplied holdfast must be installed for this purpose.
The orientation of the bracket can be selected according to customer preference:
The MAVERICK offers two mounting options on the top and two on the bottom.
This website uses cookies
We use cookies to personalise content and advertisements, to offer social media functions and to analyse access to our website. We also share information about your use of our website with our social media, advertising and analytics partners. Our partners may combine this information with other data that you have provided to them or that they have collected as part of your use of the services.
