Multi-mode fiber optic rotary joint LC/PC OM4 · 4
€1,726.00
Currently available – Delivery time upon request
Key features
Multi-mode fiber optic rotary joint LC/PC OM4 · 4
This fiber optic rotary joint uses multi-mode OM4 fibers (ISO/IEC 11801, G50/125 µm) – the highest-performing multi-mode class for short- to medium-distance transmission paths. With an insertion loss of < 2.0 dB at 850/1300 nm, this FORJ supports high-speed standards such as 10GBase-SR or 40G/100G Ethernet. The LC/PC connector technology (106024 series) enables a compact and reliable connection.
Bespoke fiber lengths (0.5 m to 2.0 m) and alternative connector types are available upon request. Please let us know what your specific needs are.
We will provide you with an estimated delivery time upon request. The exact delivery time will be communicated after receipt of order together with the order confirmation.
Specifications
- Number of channels 1
- Type of transmission multi-mode (MM) OM4 – ISO/IEC 11801 (G50/125 µm)
- Wavelength range 820–880 nm and 1280–1350 nm
- Max. insertion loss < 2.0 dB (850/1300 nm); < 3.0 dB (1550 nm)
- Variation of insertion loss during rotation < 0.5 dB
- Min. return loss > 27 dB (850/1300 nm); > 20 dB (1550 nm)
- Max. rotational speed max. 500 rpm
- Protection class IP 40
- Cable length 0.5 m to 2.0 m (standard: each 2 m)
- Type of connector (standard) LC/PC (106024 series)
- Operating temperature -40 °C to +85 °C
- Service life 200 million revolutions
- Weight < 1 kg
Typical fields of application
- Industry and automation
- Image processing
- Robotics
- Special machinery
Do you require a different connector or fiber combination?
We would be happy to help you.
